In lugnet.cad.dev, Don Heyse wrote:
| |
In lugnet.cad.dev, Travis Cobbs wrote:
| |
I have to wonder if I’m partially to blame. Perhaps the part author was
using LDView (thumbnail is linked to bigger image, generated by LDView):
Everything looks great there.
|
Yeah, your default settings tend to hide certain surface flaws. Your
light source (where is it by the way?) and smooth shading are as effective
as dim lighting and heavy makeup. Perhaps not the best thing for a parts
designer to be using. But if you zoom in for a closer look, even in
ldview you can still see the bumpy waffled surface when you spin those
parts around. And even smooth shading doesn’t completely hide the
wrinkles close up.
|
My light is a directional light pointing in exactly the same direction as the
camera. In LDView 3.1, you can actually override this with an undocumented
command line option. I hope to have light direction (single directional light)
as a new feature in LDView 3.2. Some future LDView might support more arbitrary
lighting (including multiple light sources).
| |
I wonder if there’s a way to get ldview to use a different set of
preferences when the user is obviously looking at a part?
|
I could probably do that, but the smooth shading is actually useful when editing
a part, because it can highlight missing (or incorrect) conditional lines. It’s
not fool-proof, since correct conditional lines don’t necessarily result in
smooth shading. On the other hand, I suspect that most part authors that use
LDView for inspection of their parts would prefer to have the smooth surfaces
look good in LDView.
--Travis
|
|
